Kramer VA-144 4-Channel Balanced Audio Mixer – Rack/Desk Mountable

Kramer
Kramer VA-144 4-Channel Balanced Audio Mixer – Rack/Desk Mountable

KE-VA-14

The Kramer VA-144 is a high-performance 4-channel balanced audio mixer designed for professional audio applications. It accepts any combination of balanced mic or line-level signals on XLR connectors and provides two mixed balanced outputs plus a headphone output. Each input features independent level (gain) control and selectable 48V phantom power, while the master and headphone outputs have dedicated control for precise audio management. Compact and versatile, the VA-144 can be used on a desktop or mounted in a standard 1U rack using the RK-1 rack adapter, making it ideal for studio, live sound, and AV installations.

Features & Benefits

  • 4 balanced mono audio inputs (mic or line level) on XLR (F) connectors
  • 2 balanced mono outputs on XLR (M) and 1 headphone output (6.5mm)
  • Individual gain control for each input and master/phones output
  • 48V DC phantom power selectable per input
  • Compact desktop size; rack-mountable (2 units side-by-side in 1U with RK-1)
  • High signal-to-noise ratio: Mic in → phones out 45.3dB, Line in → phones out 83.3dB, Line in → line out 84.3dB, Mic in → line out 64dB
  • Wide bandwidth: >40kHz
  • Low total harmonic distortion + noise (THD+N): Line in → line out 0.007%, Mic in → line out 0.15%
  • Adjustable input/output ranges for precise audio mixing
  • AC-coupled inputs, DC-coupled balanced line/mic outputs, AC-coupled phones
