Kramer 3232V-XL 32×32 Composite Video Matrix Switcher

KE-3232V-XL

The Kramer 3232V-XL is a high-performance 32×32 analogue composite video matrix switcher from the Lassen XL Series, designed for space- and cost-efficient installations in a compact 3RU rack-mount chassis. Delivering excellent signal integrity with a wide 300MHz bandwidth, it enables reliable routing of composite video sources in demanding AV environments. Control is available via the front panel or remotely using RS-232, RS-422 or Ethernet, making the 3232V-XL ideal for broadcast, corporate, education and large-scale video-only applications.

Variations

Features & Benefits

  • 32×32 analogue composite video matrix switcher (no audio)
  • 300MHz video bandwidth (–3dB) for high-quality signal performance
  • Front-panel and remote control via RS-232, RS-422 and Ethernet
  • 32 composite video inputs on BNC connectors
  • 32 composite video outputs on BNC connectors
  • Additional sync, RS-485 and Ethernet ports for system integration
  • Compact 3RU enclosure for standard 19-inch rack mounting
  • RJ-45 Ethernet port for network control
