GUDE 8112-2 6-Fold Switched Power Sequencer IEC

GUDE Systems
GUDE 8112-2 6-Fold Switched Power Sequencer IEC

GS-81122

GUDE Expert Power Control 8221-1 is a 19-inch, 1U intelligent PDU with 12 switched and metered outlets for IT and AV racks. It features dual power banks for independent or pairwise control, supporting different phases for flexible setup. The unit enables proactive power and environment monitoring with plug-and-play sensors for temperature, humidity, and air pressure, helping prevent physical hazards. Improve energy efficiency, cut electricity costs, and reduce CO₂ emissions with precise power management.

Features & Benefits

  • Sequential switching of up to 6 devices by simply pressing a button
  • Switching interval can be configured individually
  • Avoid critical inrush currents
  • Effectively reduce electricity costs
  • Integrated overvoltage protection type 3
  • Minimize noise through mains filter
  • Simple and quick mounting due to integrated mounting brackets
  • 6 power ports switchable via switch on the device or by external button
  • Sequential switching on and off of connected loads with a delay of 3 seconds between adjacent outputs
  • Current peaks during simultaneous switching operations (high inrush) and triggering of upstream fuses are prevented
  • Integrated type 3 overvoltage protection (according to EN61643-1) prevents damage to the device and connected loads
  • Integrated mains filter prevents interference currents and thus eliminates loss of signal quality in connected devices such as loudspeakers, amplifiers and beamers
  • Switching intervals (ON/OFF) can be set individually for each power port
  • Jack plug connector allows connection of external switch or I/O contacts for remote control of the switching routine
  • Low energy consumption
  • 19 inch, 1 HU
  • LxWxH: 43.9 x 11.2 x 4.4 cm (without mounting brackets)
  • Weight: approx. 2.1 kg
  • Cable length: 2 m
  • Operating temperature: 0-50 °C
  • Storage temperature: -20 – 70 °C
  • Relative humidity: 0 – 95 % (non condensing)
  • 1 power supply safety socket type F (max. 16 A, 230 V)
  • 6 power ports IEC C13 (max. 10 A)
  • Jack plug connector for external switch or I/O contacts
