GUDE Temperature/Humidity/Air Pressure/Signal Sensor
GS-7210
GUDE 7210 Sensor is a combined temperature, humidity, air pressure, and signal sensor with an RJ45 connector for reliable environment monitoring of GUDE devices. It enables real-time measurement and supports NO/NC inputs for external alarms such as smoke or leak detectors. With plug-and-play installation and a 40 m cable range, it offers flexible placement in server racks and AV/IT setups. Proactive monitoring helps prevent overheating, ensuring stable and safe operation of critical infrastructure.
Features & Benefits
- Can be used with all GUDE units with RJ45 sensor connection
- Additional safety through polling of 2 passive signal inputs
- Easy installation thanks to plug-and-play
- Proactive monitoring in real time
- Connection via RJ45 cable
- Supports cable length up to 40 m
- Relative humidity: 0-95% (non-condensing)
- Temperature measuring range: -20 °C to +80 °C at ±2 °C (maximum) and ±1 °C (typical)
- Humidity measuring range: 0-100% at ±3% (typical) and 10-80% at ±2% (typical)
- Air pressure measuring range 300-1100 hPa: -20 °C to 0 °C at ±1.7 hPa (typical) and 0 °C to +65 °C at ±1 hPa (typical)
- 2 LEDs for status indication of the signal inputs
- Sensor housing: plug-in plastic shells
- LxWxH: 4.2 x 2.0 x 3.5 cm
- Weight: approx. 29 g
- 1 RJ45 socket
- 2 passive signal inputs, industrial terminal, 3-fold
