Introducing the DA1414: Blustream’s Advanced Audio Matrix with Dante and USB Integration

News / 29.04.25

Blustream continues to push the boundaries of audio distribution with the launch of its latest innovation - the DA1414 Advanced Audio Matrix. Purpose-built for professional AV integrators and system designers, the DA1414 combines 14x14 channel routing, Dante/AES67 networking, USB audio support, and advanced signal processing - all within a compact, rack-mountable unit.


With an emphasis on flexibility, interoperability, and performance, the DA1414 is designed to meet the growing demands of modern AV environments, from enterprise-level multi-zone commercial installations to high-performance residential projects.


Designed for Seamless Multi-Zone Audio Distribution

At the heart of the DA1414 is a powerful matrix engine capable of independently routing and processing mono audio signals across up to 14 input and 14 output channels. This includes:


  • 8 x Dante / AES67 inputs and outputs
  • 4 x balanced/unbalanced analogue inputs and outputs
  • 2 x USB audio input and output channels


This flexible configuration allows system designers to route audio signals across multiple formats with total control and precision. Whether working with microphones, line-level sources, networked audio, or USB-connected devices, the DA1414 offers a streamlined, scalable solution.


Advanced Signal Processing and Control

Blustream understands the importance of professional-grade signal processing in delivering consistent and high-quality audio. The DA1414 includes a suite of powerful tools for tuning and managing each signal path independently, including:


  • Independent mono-channel routing and mixing
  • Per-channel volume and balance control
  • Up to 8-band parametric EQ per unit and output
  • High/low shelf and high/low pass filters
  • Selectable 48v phantom power on analogue inputs for microphones


These features make the DA1414 an ideal choice for audio-critical environments, such as conference rooms, hospitality venues, houses of worship, and educational campuses.


Enhanced USB Audio Integration

One of the standout features of the DA1414 is its comprehensive USB audio support, offering both USB-C and USB-B connections. This dual interface accommodates a wide range of devices, from modern laptops and tablets to legacy hardware. The system supports USB Audio Class 2.0, ensuring compatibility with both Mac and Windows operating systems without the need for additional drivers.


This functionality opens up new opportunities for hybrid meeting environments, where audio from USB-connected conferencing solutions can be seamlessly integrated into a wider Dante or analogue distribution network.


Built for Dante and AES67 Audio Networks

As expected from a product bearing the Blustream name, the DA1414 features robust support for Dante and AES67 audio-over-IP protocols. Key capabilities include:


  • Dual Dante LAN ports for network redundancy
  • Configurable Dante latency (2, 3, 4, 5, or 10ms)
  • 48kHz / 24-bit sampling for A/D and D/A conversion
  • Support for 44.1, 48, and 96 kHz sample rates


Importantly, the DA1414 offers API switching functionality, allowing integrators to control Dante channel routing via third-party control systems, without relying on Dante Controller or Domain Manager. This unlocks powerful automation and control capabilities within broader AV ecosystems.


Flexible Power and Installation

Designed for fast and adaptable deployment, the DA1414 supports PoE+ (IEEE 802.3at Class 4) power via the primary LAN port. Where PoE is unavailable, the unit also accepts local DC power, giving installers options to match any infrastructure.


It's 1U form factor and includes a 19” rack mounting kit, making the DA1414 easy to integrate into equipment racks, AV cabinets, or standalone installations.


Control and Integration Made Easy

The DA1414 is engineered for professional integration with multiple control options:

  • Front panel control
  • RS-232 serial control
  • TCP/IP network control
  • Web-based GUI

This multi-layered approach ensures that system managers, technicians, and end-users all have the tools they need to configure, manage, and troubleshoot the system efficiently - either locally or remotely.


Real-World Applications and Use Cases

Thanks to its comprehensive feature set, the DA1414 is ideal for a wide range of commercial and residential scenarios, including:


  • Corporate environment: Seamlessly route audio from conferencing systems, microphones, and networked media players across departments and meeting rooms
  • Educational institutions: Integrate USB-connected teaching tools with networked audio infrastructure for lectures and live streaming
  • Houses of worship: Mix and distribute microphone, musical, and streaming inputs across zones while maintaining full EQ and balance control
  • Hospitality venues: Deliver different audio feeds to restaurants, bars, lobbies, and conference spaces - all from a centralised matrix
  • Luxury residential AV: Distribute audio across home entertainment zones, with tailored EQ for each room’s acoustics


The Blustream Difference

Blustream’s reputation is built on delivering reliable, integrator-focused AV solutions that meet the needs of modern environments. The DA1414 exemplifies this philosophy, providing an advanced feature set in a robust, cost-effective package. With its combination of Dante, analogue, and USB audio capabilities, the DA1414 is not just another audio matrix - it’s a future-ready solution designed for the next generation of integrated audio systems.
